DESCRIPTION
The STRIPESORB is a stripe-shaped acoustic treatment absorber made of selfextinguishing acoustic foam. Its shape looks similar to parallel blades with angular spaces between them. It was designed in order to have small longitudinal absorption surfaces separated by small angled incisions; its shape maximizes the area that is exposed to the sound waves for better absorption.
There are two different shapes, STRIPESORB, which is flat, and STRIPESORB ARC, which describes a concave and convex arc that wave uniformly, these can be combined to offer different decorative alternatives.
It is meant to achieve a great absorption for the budget-conscious acoustic projects. Installed by gluing it directly to the existing surface with our recommended adhesives.
The STRIPESORB is recommended for project spaces, large room environments, common workspaces, music studios, listening rooms, as well as small booths. This model can be applied on large continuous areas when mandatory and stronger acoustic absorption is required, by solving excessive reverberation problems as well as flutter echo problems.
The STRIPESORB is a stripe-shaped acoustic treatment absorber made of selfextinguishing acoustic foam. Its shape looks similar to parallel blades with angular spaces between them. It was designed in order to have small longitudinal absorption surfaces separated by small angled incisions; its shape maximizes the area that is exposed to the sound waves for better absorption.
There are two different shapes, STRIPESORB, which is flat, and STRIPESORB ARC, which describes a concave and convex arc that wave uniformly, these can be combined to offer different decorative alternatives.
It is meant to achieve a great absorption for the budget-conscious acoustic projects. Installed by gluing it directly to the existing surface with our recommended adhesives.
The STRIPESORB is recommended for project spaces, large room environments, common workspaces, music studios, listening rooms, as well as small booths. This model can be applied on large continuous areas when mandatory and stronger acoustic absorption is required, by solving excessive reverberation problems as well as flutter echo problems.
FEATURES
TECHNICAL DRAWINGS
PRODUCT DIMENSIONS
Model | Height | Width | Depth | Weight | |
---|---|---|---|---|---|
|
STS120sq | 120 cm (47,2") | 120 cm (47,2") | 8 cm (3,1") | 1.6 kg (2 lbs 24 oz) |
|
STS120 | 120 cm (47,2") | 60 cm (23,6") | 8 cm (3,1") | 0.8 kg (1 lbs 12 oz) |
|
STS060 | 60 cm (23,6") | 60 cm (23,6") | 8 cm (3,1") | 0.4 kg (0 lbs 14 oz) |
|
STS120/6sq | 120 cm (47,2") | 120 cm (47,2") | 6 cm (2,2") | 1,2 kg (2 lbs 10 oz) |
|
STS120/6 | 120 cm (47,2") | 60 cm (23,6") | 6 cm (2,3") | 0.6 kg (1 lbs 5 oz) |
|
STS060/6 | 60 cm (23,6") | 60 cm (23,6") | 6 cm (2,3") | 0.3 kg (0 lbs 11 oz) |
ABSORPTION COEFFICIENT
USED BY
PRODUCT DATA
Get in
touch
Text to us and tell us all your wishes
as your closest friend.
IMPORTANT NOTICE
IMPORTANT NOTICE
JOCAVI™ products are fire retardant and/or self extinguishing to varying extents. Before purchasing any of our acoustic foam products, please check with your local fire marshal or building inspector for approval. We cannot guarantee that any product meets the specific building code regulations in your area/country as regulations widely vary from place to place. JOCAVI™ will not be held liable for property damage or injuries caused by the misuse of our products.
Given the fragility and sensitivity of the raw materials used in the ATP™ product range, we advise and recommend these products are not installed within reach of physical contact by people or objects. Physical contact may damage these products.
Sizes may slightly vary due to their production method and some inherent raw-materials characteristics. Despite all the standard sizes of all products, some models can be customised upon previous consultation. Sizes may slighty vary due to their production method and some inherent raw-materials characteristics.
