DESCRIPTION
BASMEL is a low-cost acoustic panel set to be applied in large quantities on ceilings and walls. It’s made of flexible open-cell melamine resin foam or of regular acoustic foam, a thermoset polymer and a fire-resistant fabric-finishing surface. The sound waves penetrate the open-cell structure, thus reducing the reflected energy and giving this product an excellent sound absorption capacity and simultaneously improving soundproofing, thereby providing safety in accordance with environmental standards.
Several available options: one flat (BAL060/120), other one perforated MABS060 (with the same pattern from the COSMOS model), BASMEL SC (with more thickness and side covered with fabric - thus reducing the reflected energy and giving this product an excellent sound absorption capacity), BASMEL Plates (with more coverage area) and the most recent, the BASMEL Twist and BASMEL Bevel. All these models have different possibilties (different foams, fabric colours, shapes, etc).
The BASMEL’s acoustic and safety characteristics make this product ideal for use as a noise control and sound insulation device in buildings that have demanding requirements against fire. It improves acoustics and soundproofing, thereby providing safety in accordance with environmental standards.
Homes, meeting rooms, offices and hotel foyers can be acoustically upgraded just as effective and attractive by using this product. The installation method is very simple by using mounting glue or can be provided with self-adhesive on the back. To conceal the union between the panels, we also have, as an option, a roll of fabric adhesive tape(with 500x3cm) that can be applied.
FEATURES
AVAILABLE FINISHINGS
Regular foam:
Fabric colours
TECHNICAL DRAWINGS
PRODUCT DIMENSIONS
Model | Height | Width | Depth | Weight | |
---|---|---|---|---|---|
|
BAL024ch | 24 cm (9,4") | 24 cm (9,4") | 4 cm (1,6") | 0.048 kg (0 lbs 2 oz) |
|
BAL060 | 60 cm (23,6") | 60 cm (23,6") | 4 cm (1,6") | 0.3 kg (0 lbs 11 oz) |
|
BAL120 | 120 cm (47,2") | 60 cm (23,6") | 4 cm (1,6") | 0.5 kg (1 lbs 2 oz) |
|
BAL200.2 | 200 cm (78,7") | 120 cm (47,2") | 2 cm (0,8") | 1.12 kg (2 lbs 8 oz) |
|
BAL200.4 | 200 cm (78,7") | 120 cm (47,2") | 4 cm (1,6") | 2.24 kg (4 lbs 15 oz) |
ABSORPTION COEFFICIENT
USED BY
PRODUCT DATA
Get in
touch
Text to us and tell us all your wishes
as your closest friend.
IMPORTANT NOTICE
IMPORTANT NOTICE
JOCAVI™ products are fire retardant and/or self extinguishing to varying extents. Before purchasing any of our acoustic foam products, please check with your local fire marshal or building inspector for approval. We cannot guarantee that any product meets the specific building code regulations in your area/country as regulations widely vary from place to place. JOCAVI™ will not be held liable for property damage or injuries caused by the misuse of our products.
Given the fragility and sensitivity of the raw materials used in the ATP™ product range, we advise and recommend these products are not installed within reach of physical contact by people or objects. Physical contact may damage these products.
Sizes may slightly vary due to their production method and some inherent raw-materials characteristics. Despite all the standard sizes of all products, some models can be customised upon previous consultation. Sizes may slighty vary due to their production method and some inherent raw-materials characteristics.
