DESCRIPTION
The IVORY is a 2D controlled dispersion diffusion panel in a single coordinate. It is made of high-density EPS covered with a hardened layer. This design gives this product the intended acoustic diffusion properties. It is therefore one more option within the range of diffusers presented by ATP™.
Its convex external geometry with seven longitudinal incisions provides a decorative effect and attractive combinations with the absorption panel EBONY.
The use of this extremely dynamic panel is crucial to control early reflections and other reflections from walls, thus improving control of sound diffusion in the room.
Due to its shape, with deep recesses, this product also has an interesting related absorption coefficient.
This acoustic panel is installed on walls and ceilings. Its low weight makes its installation on ceilings quite practical.
FEATURES
AVAILABLE FINISHINGS
EPS:
TECHNICAL DRAWINGS
PRODUCT DIMENSIONS
Model | Height | Width | Depth | Weight | |
---|---|---|---|---|---|
|
IVO060 | 60 cm (23,6") | 60 cm (23,6") | 14 cm (5,5") | 2.4 kg (5 lbs 5 oz) |
|
IVO120 | 120 cm (47,2") | 60 cm (23,6") | 14 cm (5,5") | 4.8 kg (10 lbs 9 oz) |
ABSORPTION COEFFICIENT
RELATED VIDEOS
USED BY
PRODUCT DATA
Get in
touch
Text to us and tell us all your wishes
as your closest friend.
IMPORTANT NOTICE
IMPORTANT NOTICE
JOCAVI™ products are fire retardant and/or self extinguishing to varying extents. Before purchasing any of our acoustic foam products, please check with your local fire marshal or building inspector for approval. We cannot guarantee that any product meets the specific building code regulations in your area/country as regulations widely vary from place to place. JOCAVI™ will not be held liable for property damage or injuries caused by the misuse of our products.
Given the fragility and sensitivity of the raw materials used in the ATP™ product range, we advise and recommend these products are not installed within reach of physical contact by people or objects. Physical contact may damage these products.
Sizes may slightly vary due to their production method and some inherent raw-materials characteristics. Despite all the standard sizes of all products, some models can be customised upon previous consultation. Sizes may slighty vary due to their production method and some inherent raw-materials characteristics.
