DESCRIPTION
The REFLEX represents another option on acoustic diffusers, thus allowing different aesthetic and performance possibilities. It is made of high-quality 100% recyclable ecologic EPS raw material. It is used on side or back walls to blend the direct and early reflected sound, thus increasing speech intelligibility and enhancing musical clarity.
This diffusion panel offers optimal shape and more omnidirectional scattering diffusion than traditional, non-optimised panels do. It is a very good cost-effective choice for a 2D sound diffuser.
FEATURES
Average diffusion
0.50/m2 [>100Hz;<5KHz]
NRC
0.26/m2 [>250Hz;<10KHz]
Fire resistance
Euroclass B-s3,d1 (similar to old M1)
Finished with
An ecological paint
Very easy to install
with mounting *glue without solvents - (*sold separately)
Colours:
Other colours available upon consultation
AVAILABLE FINISHINGS
EPS:
Similar to RAL 1011
Beige
Similar to RAL 9005
Black
Similar to RAL 5013
Blue
Similar to RAL 8019
Brown
Similar to RAL 6028
Green
Similar to RAL 7015
Grey
Similar to RAL 5010
Light blue
Similar to RAL 7001
Light grey
Similar to RAL 2001
Orange
Similar to RAL 4007
Purple
Similar to RAL 3003
Red
Similar to RAL 9003
White
Similar to RAL 1003
Yellow
TECHNICAL DRAWINGS
PRODUCT DIMENSIONS
Model | Height | Width | Depth | Weight | |
---|---|---|---|---|---|
|
RFL060 | 60 cm (23,6") | 60 cm (23,6") | 10 cm (3,9") | 0.8 kg (1 lbs 12 oz) |
|
RFL120 | 120 cm (47,2") | 60 cm (23,6") | 10 cm (3,9") | 1.6 kg (3 lbs 8 oz) |
ABSORPTION COEFFICIENT
